Name

Prep-station

Model

GS700AB

Specification

Fan Cabin Size(mm)

3450×1100×2000

Total Power

5.5KW

Circulation System

    1、Inlet Fan Model: Centrifugal YDW-5.6S；Air Capacity:15000m³/h；Pressure 800Pa； Rotate Speed ：900rpm；Power: 5.5KW；Qty：1 set
    2、 Fan Cabin ： Profile framework, Assembly of steel plate cabin;Consturcion: Solid, beautiful and easily to maintain 。

Purification System

Filtering stucture: mutli-storey fixed under the top network, no corrosion, and can capture guanules larger than 5um.

Controlling System

     It is assembled by good electronic components.Maini circuit has multi-protection.working switch,light switch, emergency Stop,breakdown alarm. .
