Test Line
GTL-100
Model: GTL-100
Description
Technical Features & Functions
GTL-100 Vehicle Automatic Steering Angle Tester can test the max. steering angle of front wheels, camber of front wheels, inclination of kingpin, reverse caster and toe-in of front wheels;
Able to test the steering force and free rotation of steering wheel;
Able to adapt to the wheel distance of various vehicles automatically, with simple measurement process;
User-friendly, able to conduct data communication with other computer management systems.
Technical Parameters:
| Max. Allowed Axle Weight | 1000 kg |
| Test Ranges | +/-50 |
| Wheel Tread (Inner/Outer mm) | 700/2700 |
| King Pin Inclination Tolerance | 0.2 |
| Caster Tolerance | 0.2 |
| Camber Tolerance | 0.2 |
| Max. Turning Angle Tolerance | 0.2 |
| Front Toe-in Tolerance | 0.5 |
| Turningplate Moving Speed | 15.5m/min. |
| Dimension | 3800 x 880 x 420 (mm) |
